Overview:
The ICON Vehicle Dynamics 3" Lift Suspension System is designed for Jeep JK owner's demanding the ultimate in performance and ride quality, without the larger stance you find in bigger lift systems on today's market. ICON's Jeep Wrangler JK 3" lift system is engineered with front and rear dual rate progressive wound springs which is the foundation for on and off road performance and suspension articulation. The dual rate design gives you a softer initial rate for superb on road comfort and a firmer than stock secondary rate that increases during compression for excellent bottom out control. ICON V.S. 2.0 Aluminum Series Remote Reservoir shocks add the finishing touch with OE mounting, aircraft grade components, and vehicle specific valving. Remote Reservoir shocks are great for additional heat disipation to prevent shock fade during off road use. Together the combination of ICON dual rate coils and V.S. 2.0 Aluminum Series shocks adds 30% more wheel travel over stock, helping you rock crawl safer or soak up larger terrain at higher speeds keeping those wheels on the ground. In this Stage 3 system adjustable track bars are include front and rear for optimizing axle position to ensure your axles are perfectly centered under the vehicle. This ICON 3" JK lift system is designed from the ground up to give the 07+ Jeep Wrangler JK's the best performance, suspension handling / ride quality, and clearance for 33" tall tires (35" tall with installation of aftermarket high-clearance fenders).
Key Features:
Dual Rate Coil Springs Front and Rear
Adds 30% More Wheel Travel over Stock
Level Stance Front to Rear
Vehicle can be Returned Back to Stock
No Welding or Cutting
Includes High Performance Re-buildable / Re-valvable Remote Reservoir 2.0 Aluminum Series Shocks
Out Articulates Most Long Arm Kits of Comparable Height
Includes Adjustable Track Bars for Optimized Axle Positioning
Pan Rod Bars include Dual Stage Bushing System and JM12T Rod End to minimize deflection while maximizing responsiveness
Made in the USA
Lifetime Guarantee that Coil Springs Won t Sag
Tech Info:
Fits 2007 - Current Jeep Wrangler JK 2wd or 4wd models
2 Door Models sit 1/2" - 3/4" taller than 4 door models but still level
2012 models require exhaust extension kit (Part # 22011) for proper front driveline clearance
No driveline modifications necessary if kit is installed as intended (with or without track bars)
Front End Alignment Required
Wheel & Tire Fitment Info:
OEM Wheels & Tires: Yes
AfterMarket Wheels: 4.5" Backspace
(wheel spacers required to run factory wheels with an over sized tire)
Aftermarket Tires: 33" tall x 12.50"
(Larger 35" tire packages will fit with minor modifications or aftermarket high clearance fenders, test fitment recommended)
System Components Included:
2007 - Current Jeep JK - 3" Suspension Lift System Stage 3
22010 (QTY - 1) Jeep JK 3" Front Dual Rate Spring Kit (Pair)
22015 (QTY - 1) Jeep JK 2" Rear Dual Rate Spring Kit (Pair)
22040 (QTY - 1) Jeep JK 3" Lift Box Kit (front and rear billet bump stops / front sway bar links / hardware)
21020 (QTY - 1) Jeep JK Front Adjustable Pan Rod Bar Kit
21025 (QTY - 1) Jeep JK Rear Adjustable Pan Rod Bar Kit
26519R (QTY - 2) JK 2WD & 4WD 2 -3" Lift Remote Reservoir Front Shock - 2.0 Aluminum Series
26520R (QTY - 2) JK 2WD & 4WD 2 -3" Lift Remote Reservoir Rear Shock - 2.0 Aluminum Series
Options:
27820 Jeep JK 2WD & 4WD 2 -3" Lift 2.5" V.S. Series Remote Reservoir Front Shocks
27725 Jeep JK 2WD & 4WD 2 -3" Lift 2.5" V.S. Series Piggyback Reservoir Rear Shocks
27820C Jeep JK 2WD & 4WD 2 -3" Lift 2.5" V.S. Series Remote Reservoir Front Shocks w/ CDCV
27725C Jeep JK 2WD & 4WD 2 -3" Lift 2.5" V.S. Series Piggyback Reservoir Rear Shocks w/ CDCV
29920 Jeep JK 2WD & 4WD 2 -3" Lift 2.5" Omega Series Bypass Remote Reservoir Front Shocks
29925 Jeep JK 2WD & 4WD 2 -3" Lift 2.5" Omega Series Bypass Piggyback Reservoir Rear Shocks
22011 Jeep JK Exhaust Extension Kit
22012 Jeep JK Alignment Cam and Knock out Tool Kit
22013 Jeep JK Alignment Cam Kit (Fits in Front Lower or Rear Upper Link position)
22014 Jeep JK Replacement Front Drive Shaft w/ Yoke Adapter (2012 - Current)
22016 Jeep JK Replacement Front Drive Shaft w/ Yoke Adapter (2007 - 2011)
22017 Jeep JK Alignment Cam Knock out Tool
22018 Jeep JK High-Clearance Steering Stabilizer Kit
22019 Jeep JK Front Hydraulic Bumpstop System
21031 Jeep JK Front Lower Fixed Link Kit
21036 Jeep JK Front Upper Adjustable Link Kit
21041 Jeep JK Rear Lower Adjustable Link Kit
21046 Jeep JK Rear Upper Fixed Link Kit
614600 2.0 Aluminum Shock Reservoir Clamp Kit - 2.0 to 2.0 (hose clamp w/ rubber spacer included standard)
611058 Jeep JK Front Remote Reservoir 2.0 / 2.5" Shock Resi Mount Kit (each)
(Standard kit mounts the Remote Reservoirs to the body of the shock. Use this bracket to mount the
Reservoir forward of the coil bucket to the frame like the picture above)
